CENTR 1 - Step 8 Assembly

Pg. 18 V07122023-C5

2525
2424
2626
99
2727
2828
25
24
26
9
27
28
(48) BOLT, M10 X 1.5 X 75, SH, BZ, .
(25) WASHER, FLAT, 11 X 20 X 2, BZ, .
(26) NUT, M10 X 1.5, LOCK, BZ, .
(27) BOLT, M8 X 1.25 X 15, SH, BZ, .
(28) WASHER, FLAT, 8.5 X 16 X 2, BZ, .
HARDWARE REQUIRED:
26
9
48
25
27
28

