For technical questions, please call 1-800-444-3353.
SKU 32879
Insert the Handle into the Plunger/2.
Fulcrum Assembly. Apply pressure
to the Saddle, and pump the Handle
quickly several times.
Check the Oil Fill Hole and, if 3.
necessary, top off the Oil Fill Hole
with hydraulic oil.
Replace the Oil Filler Plug.4.
Test the Jack several times before 5.
putting into use. If, after purging,
the Jack still does not appear to be
working properly, do not use the
Jack until it has been repaired by a
qualied service technician.
General Operating Instructions
The Shop Press can be used for
a variety of functions including
electric motor and armature
repair, installation and removal of
pressure tted parts such as gears
and bearings, and bending or
straightening of metal. Care should
be taken in set up and operation of
the Shop Press to avoid damage or
injury.
To operate the Shop Press:
Use the Pins (6) to adjust the height 1.
of the Press Apron (5).
Note: The Press Apron (5) should be in
the highest position possible with the
workpiece as close as possible to the
ram of the Jack Plate (2).
Place the item to press between the 2.
Arbor Plates (3).
WARNING: Make sure there is no
obstruction (such as a stray bolt or
debris) under the Arbor Plates. Such
items create an uneven surface
which can cause the Arbor Plates to
break under pressure.
WARNING: When pressing two items
together, the items must be lined
up vertically. If not, one item may
forcefully eject itself sideways from
the unit.
Using the Jack Handle (15), jack 3.
down the Jack Plate until the ram
of the Jack Plate contacts your
workpiece. Make sure if you are
pressing two items together, that they
are in vertical alignment. Continue to
operate the Handle to press the work
piece.
When the task is completed, be 4.
careful when releasing Jack pressure.
For safety, remove the Handle, then
use the Handle to slowly turn the
Valve Release Screw on the Jack,
allowing the Jack Plate to rise.
WARNING: After pressing, during the
release process the Jack may rise
quickly. Stay clear.
