UNPACKING
When unpacking, make sure that the
product is intact and undamaged. If any
parts are missing or broken, please call
Harbor Freight Tools at 1-800-444-3353 as
soon as possible.
OPERATION
Bleeding
IMPORTANT!
for proper hydraulic oil level in the
Jack for proper operation prior to
not
be necessary to bleed its hydraulic
Oil Fill Plug
1. Remove the cover plate (some mod-
els) and the Oil Filler Plug under-
neath. (See Photo above.)
Release Screw
Pivot Assembly
2. -
Insert the slot on the lower portion of
the Handle over the Release Screw
to operate it.
3.
built into the pivot point:
Rotate the handle to operate the Re-
lease Screw.
Turn the Release Screw 4. counter-
clockwise to open valve.
Insert the Handle into the Pivot As-5.
sembly (See photo above.) Apply
pressure to the Saddle, and pump the
Handle quickly several times.
Check the Oil Fill Hole and, if nec-6.
essary, top off the Oil Fill Hole with
hydraulic oil.
Close the valve Release Screw by 7.
turning handle clockwise and replace
the Oil Fill Plug and cover plate.
Test the Jack several times for proper 8.
operation before attempting to lift a
load.
still does not
