Central Machinery 61373 - Parts List and Diagram

Page 14 For technical questions, please call 1-800-444-3353. Item 61373
SAFETY OPERATION MAINTENANCESETUP
Part Description Qty
1 Machine Body / Cutting Wedge 1
2 Ram Cap and Shaft 1
3 Upper Nylon Cushion 1
4 Lower Nylon Cushion 1
5 Ram Base Plate 1
6 Flat Washer M8 X 1 6
7 Spring Washer M8 X 2.3 6
8 Inner Hex Bolt M8 X 15 6
9 Double-Screw Bolt M10 X 813 4
10 Cylinder Tube Ø55 X 743 1
11 Seal Ø55 x 3.1 1
12 Seal Cover 1
13 Piston Head 1
14 O-Ring Ø50 x 3.5 1
15 Piston Shaft 1
16 Retracting Spring 1
17 Nut M14 4
18 Lock Nut M14 2
19 Paper Seal Ring 2
20 O-Ring Ø30 x 2.65 1
21 Dust Seal 1
22 Reservoir Cover 1
23 O-Ring Ø6 x 1 1
24 Vent Plug M4 x 10 1
25 Copper Seal Washer M14 x 1 1
26 Drain Bolt / Dipstick 1
27 Hydraulic Valve 1
28 O-Ring Ø14 x 2.4 4
29 Flat Washer M10 x 1 4
30 Spring Washer M10 x 2 4
31 Nut M10 4
32 Shield 1
33 Flat Washer M10 x 2 4
34 Snap Head Nut M10 4
35 Torsion Spring 1
36 Control Handle Bracket 1
37 Control Handle Lever Ø12.5 X 134 1
38 Fluid Tube Ø14 / Ø10 x 100 x 1 1
39 O-Ring Ø18 x 1.9 2
40 Copper Seal Washer M14 x 1 2
41 Fluid Tube Screw M14 x 30 2
42 Inner Hex Bolt M8 x 20 4
43 Spring Washer M8 x 2.3 4
Part Description Qty
44 Hydraulic Pump 1
45 O-Ring Ø18 x 1.9 1
46 Fluid Suction Tube Ø14 / Ø10 x 100 x 1 1
47 Copper Seal Washer M14 X 1 3
48 Fluid Tube Screw M14 X 30 2
49 Fluid Filter 1
50 Inner Hex Bolt M8 x 35 4
51 Spring Washer M8 x 2.3 4
52 Flat Washer M8 x 1 4
53 Electric Motor 1
54 Fan 1
55 Shaft Circlip Ø16 1
56 Fan Cover Ø162 1
57 Flat Washer M4 x 1 3
58 Phillips Head Screw M4 x 10 3
59 Outlet Box 1
60 Rubber Gasket 1
61 Outlet Box Cover 1
62 Phillips Head Screw M4 x 10 6
63 Power Switch 1
64 Capacitor 60uf 1
65 Cable Fastener Nut 1
66 Cable Fastener 1
67 Cable Fastener Bolt 1
68 Power Cable Sleeve 1
69 Power Cable 1
70 Front Leg 1
71 Phillips Head Screw M6 x 15 4
72 Flat Washer M6 x 1 8
73 Spring Washer M6 x 2 4
74 Nut M6 4
75 Rubber Foot 2
76 Lift Handle 1
77 Phillips Head Screw M6 x 15 2
78 Guide Plate 2
79 Flat Washer M8 X 1 4
80 Spring Washer M8 X 2 4
81 Inner Hex Bolt M8 X 12 4
82 Wheel Frame 1
83 Flat Washer M17 x 2 2
84 Rubber Wheel 2
85 Flat Washer M10 x 1 2
86 Lock Nut M10 2
Parts List and Diagram
Parts List
