12
ASSEMBLY
ASSEMBLING THE RUBBER FOOT AND
WHEELS
See Figure 3.
Mount the rubber feet as shown in figure.
Tighten firmly with an open-end wrench (not included)
to secure it in position.
Mount the wheels as shown in figure.
Tighten firmly with an open-end wrench (not included)
to secure the wheels in position.
Fig. 3
WHEEL
SCREW
NUT
WASHER
SCREW
RUBBER
FOOT
WASHER
WASHER(s)
NUT
