Page 18 For technical questions, please call 1-888-866-5797. Item 62913
SAFETY OPERATION MAINTENANCEINSTALLATION
Part Description Qty
1 Exhaust Elbow 3
2 Spring Washer 8
3 Bolts M10×50 8
4 Tube 1
5
First Stage Cylinder
Head (Iron)
2
6 Safety Valve 1
7 T-Type Exhaust Tee 1
8 Muffler 2
8-1
Muffler Aluminium
Joint
1
8-2 Muffler Gasket 1
8-3 Muffler Seat 1
8-4 Air Filter 1
8-5 Muffler Cover 1
8-6 Flat Washer 1
8-7 Wing Nut M6 1
9
Cylinder Head
Sealing Gasket
2
10 Valve Plate Assembly 2
10-1 Bolt M5×12 2
10-2 Spring Washer 2
10-3 Lift Limiter 1
10-4 Exhaust Valve Piece 1
10-5 Valve Plate 1
10-6 Intake Valve Slice 1
10-7 Cylindrical Pin Ø3×8 2
10-8 Spring Sheet 1
11 Valve Plate Seal 2
12 Bolts M10×25 12
13 Spring Washer 25
14 Cylinder 2
15 Cylinder Seal 3
16 Piston Ring Ø90 2
17 Hole Circlip Ø20 4
18 Piston Pin Ø20×80 2
19 Piston (Aluminum) 2
20
Connecting Rod
(Oblique)
1
21
Connecting Rod
(Straight)
1
22 Tube 1
Part Description Qty
23 Bolts M8×50 4
24 Spring Washer 4
25
Second Stage
Cylinder Head
1
26 Cylinder Head Gasket 1
27 Valve Plate 2
28
Valve Plate
Aluminum Seal
1
29 Valves 2
30 Valve Plate Seal 1
31 Cylinder 1
32 Piston Ring 1
33 Hole Circlip 2
34 Piston (Iron) 1
35 Piston Pin 1
36 Connecting Rod 1
37 Bolts M6×20 4
38 Spring Washer 4
39
Small Square
Back Cover
1
40 Back Cover Gasket 1
41 Oil Sight Glass 1
42 Oil Sight Gasket 1
43 Drain Plug 1
44 Crankcase 1
45 Oil Plug Seal 1
46 Oil Plug 1
47 Bearing 1
48 Shaft Circlips Ø30 1
49 Shoulder Ring 1
50 Crankshaft 1
51 Woodruff Key 1
52 Bearing 1
53 Oil Seal 1
54 Front Cover Gasket 1
55 Front Cover 1
56 Breathing Gasket 1
57 Connecting Rod (Iron) 1
58 Breathing 1
59 Spring Washer 6
60 Bolt M8×25 6
61 Belt Pulley 1
62 Pulley Retaining Ring 1
Part Description Qty
63 Bolt M10×35 1
64 Exhaust Tube 1
65 Air Outlet 1
66 Tank 1
67 Drain Valve 1
68 Nut M10 12
69 Flat Washer 12
70 Bolt M10×35 4
71 Combination Valve 1
72 Elbow 1
73 Unloading Tube 1
74 Throttle Push Rod 1
75 Safety Valve 1
76 Tank Pressure Gauge 1
77 Copper Tee 1
78 Wiring Stake 2
79 Bolt M10×35 4
80 Threaded Rod 1
81 Tense Card 1
82 Flat Washer 1
83 Spring Washer 1
84 Nut M12 1
85 Bottom Plate 1
86 Socket Cap Screw 4
87 Gasoline Engine 1
88
Gasoline Engine
Pulley
1
89 Pulley Retainer Ring 1
90 Spring Washer 1
91 Bolt 3/8″×1-1/2 1
92 V-Belt 2
93 Belt Guard Frame 1
94 Flat Washer 13
95 Spring Washer 13
96 Bolt M8×20 13
97 Belt Guard Cover 1
98 Belt Guard Bracket 1
99 Bolt M6×16 1
100
Standard Spring
Washer
1
101 Flat Washer 1
102 Nut 1
103 Belt Guard Bracket 1
Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
