K3.,0(&<7)N<'(,+8(&*<'
)M.0=)(2.):OINM:)NPLKMIHOI)GH?:IJ)NO?KMPHINKO)'.8(&*<)0()(2.)/.7&<<&<7)*6)(2&')
90<+0;)&<8;+=&<7)0;;)(.^()+<=.,)'+/2.0=&<7')(2.,.&<)/.6*,.)'.()+3)*,)+'.)*6)(2&')3,*=+8(5
N<'3.8()I**;)/.6*,.)+'.A);**\&<7)6*,)=0907.=A);**'.A)0<=)9&''&<7)30,('5))
N6)0<X)3,*/;.9')0,.)6*+<=A)=*)<*()+'.)I**;)+<(&;),.30&,.=5
S*,\3&.8.)0<=)S*,\)H,.0)G.()R3
1. Designate a work area that is clean and well-lit.
The work area must not allow access by children
or pets to prevent distraction and injury.
2. Route the air hose along a safe route to reach
the work area without creating a tripping hazard
or exposing the air hose to possible damage.
The air hose must be long enough to reach
the work area with enough extra length to
allow free movement while working.
3. Secure loose workpieces using a vise or clamps
(not included) to prevent movement while working.
4. There must not be hazardous objects
(such as utility lines or foreign objects) nearby
that will present a hazard while working.
G&<7;.BG.@+.<(&0;)H8(+0(&*<)P.820<&'9)W.6&<&(&*<
The single-sequential actuation mechanism is designed to allow accurate placement of fasteners. Use the
switch near the trigger to change modes. The Tool should only actuate if the Workpiece Contact is pressed
against the workpiece prior to pulling the Trigger. It should only actuate again if the Trigger is released and
squeezed again. The Tool should not actuate if the Workpiece Contact is not pressed against an object.
G&<7;.BG.@+.<(&0;)H8(+0(&*<)P.820<&'9)I.'(&<7)L,*8.=+,.
IK)LM:%:OI)G:MNKRG)NO[RMJ)?MKP)HQQNW:OIHV)WNGQZHMT:1)
L*&<()(2.)(**;)0()0)3&.8.)*6)'8,03)-**=)-2.<)(.'(&<75
1. Disconnect the Tool from the air supply.
2. Load the magazine with fasteners.
3. Check that the Trigger and the Workpiece
Contact move freely, without sticking.
4. Connect the air supply to the Tool and
set within the Operating Air Pressure
indicated on the Specification chart.
5. Test the Tool by pressing the Workpiece Contact
against the workpiece without pulling the Trigger.
I2.)I**;)9+'()<*()8X8;.)g08(+0(.h5
If it cycles (actuates), stop immediately and have
it repaired by a qualified service technician.
6. Hold the Tool away, or off of the workpiece.
The Workpiece Contact should return to its original
position. Squeeze the Trigger.
I2.)I**;)9+'()<*()8X8;.)g08(+0(.h5
If it cycles (actuates), stop immediately and take
the Tool to a qualified service technician.
7. Press the Workpiece Contact against the workpiece
and squeeze the Trigger.
I2.)I**;)9+'()8X8;.)g08(+0(.h)*<;X)*<8.5
Release the Trigger, slide the Tool to a fresh piece of
wood, and squeeze it again.
I2.)I**;)9+'()8X8;.)g08(+0(.h)070&<)*<;X)*<8.5
With the Trigger depressed, carefully lift the Tool and
press it against the workpiece again.
I2.)I**;)9+'()<*()8X8;.)g08(+0(.h5
If it fails to act in the manner explained in bold,
have it repaired by a qualified service technician.
