Central Pneumatic 66984 - Parts List

SKU 66984 For technical questions, please call 1-800-444-3353. Page 13
Part Description Qty
1 Screw 1
2 Hammer Case 1
3 Screw 4
4 Washer 4
5 Anvil Bushing 1
6 Hog Ring 1
7 O-Ring 1
8 Anvil 1
9 Pin 2
10 Hammer Cage 1
11 Hammer 2
12 Gasket 1
13 Housing 1
14 Bearing 1
15 Front End Plate 1
16 Pin 1
17 Rotor 1
18 Vane 6
19 Cylinder 1
20 Rear End Plate 1
21 Pin 1
22 Bearing 1
Part Description Qty
23 Gasket 1
24 Rear End Plate 1
25 Gasket 4
26 Screw 4
27 Valve Bushing 1
28 Valve 1
29 Steel Ball 1
30 Spring 1
31 O-Ring 1
32 Inlet Gasket 1
33 Regulator Knob 1
34 Rubber Gasket 1
35 Air Inlet Valve 1
36 Spring 1
37 Plastic Cover 1
38 Air Inlet 1
39 Trigger 1
40 Pin 1
41 Gasket 1
42 O-Ring 1
43 Air Inlet Screen 1
PARTS LIST
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Problem Possible Causes Likely Solutions
Severe air
leakage.
(Slight air leakage
is normal,
especially on older
tools.)
1. Cross-threaded housing
components.
2. Loose housing.
3. Damaged valve or housing.
4. Dirty, worn or damaged valve.
1. Check for incorrect alignment and uneven
gaps. If cross-threaded, disassemble and
replace damaged parts before use.
2. Tighten housing assembly. If housing cannot
tighten properly, internal parts may be
misaligned.
3. Replace damaged components.
4. Clean or replace valve assembly.
Follow all safety precautions whenever diagnosing or servicing the
tool. Disconnect air supply before service.
