Page 18 For technical questions, please call 1-800-444-3353. Item 69575
Part Description Qty
1 Set Screw 1
2 Air Deflector 1
3 O-Ring 1
4 O-Ring 1
5 Hex Bolt 6
6 Spring Washer 1
7 Air Cap 1
8 Seal 1
9 Spring 1
10 O-Ring 3
11 Head Valve Piston 1
12 O-Ring 1
13 Gasket 1
14 Lining Ring 1
15 O-Ring 1
16 O-Ring 1
17 Driver Blade Unit 1
18 O-Ring 1
19 Cylinder 1
20 O-Ring 1
21 Bumper 1
22 Body 1
23 Nozzle 1
24 Safety Guide 1
25 Safety Guide Pin 2
26 Spring 1
27 Depth Control Guide Body 1
28 Depth Adjustment Knob 1
29 Lock Nut 4
30 Safety Nosepiece 1
31 No-Mar Tip 1
32 Switch Unit 1
33 Spring 1
34 Trigger Plate Pin 2
35 Trigger Plate 1
36 Trigger 1
37 Trigger Pin 1
Part Description Qty
38 O-Ring 1
39 Set Screw 1
40 Driver Guide Cover 1
41 Spring 1
42 Baffle Board 1
43 Driver Guide 1
44 Set Plate 1
45 Cover Plate 1
46 Hand Grip 1
47 Quick Release Lever 1
48 Quick Release Lever Pin 1
49 Latch 1
50 E-Ring 1
51 Pin 1
52 Spring 1
53 Pusher 1
54 Support 1
55 Pusher Latch 1
56 Nail Guide Plate 2
57 Magazine 1
58 Hex Bolt 2
59 Set Screw 1
60 Rear Cover 1
61 Rear Cover Pin 1
62 Clapboard Pin 2
63 Clapboard 1
64 Hex Bolt 2
65 Tail Hanger 1
66 Hex Bolt 1
67 Lock Nut 1
68 Head Grip 1
69 Gasket 1
70 C-Ring 1
71 Filter 1
72 End Cap 1
73 Hex Bolt 3
74 Air Plug 1
Parts List and Diagram
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
