Page 8 For technical questions, please call 1-800-444-3353. Item 69575
Components and Controls
Safety Nosepiece - Also called the workpiece contact, the Safety Nosepiece helps
prevent the tool from firing unless it is pressed against an object.
Trigger
Air Inlet Plug
Safety Nosepiece
Magazine
Air Deflector
Pusher
Depth
Adjustment Knob
SAFETY OPERATION MAINTENANCESETUP
