Page 6 For technical questions, please call 1-800-444-3353. Item 93100
SAFETY OPERATION MAINTENANCESETUP
Functional Description
Specifications
Maximum Torque 75 ft-lb
Maximum Air Pressure 90 PSI
Air Inlet 1/4″ -18 NPT
Maximum Speed* 10,000 RPM
Impact Rate 1000 BPM
Average Air Consumption 4 CFM @ 90 PSI
Recommended Hose Size 3/8″
* Maximum speed at stated maximum air pressure.
Excess air pressure is hazardous and may cause
the tool to exceed stated maximum speed.
Components and Controls
Figure 1
Anvil (9)
Throttle Lever (5)
Air Regulator (38)
Air Inlet (36)
(Reverse)
(Forward)
