Page 14 For technical questions, please call 1-888-866-5797. Item 93458
Part Description
1A Nosepiece (3/16″)
1B Nosepiece (5/32″)
1C Nosepiece (1/8″)
1D Nosepiece (3/32″)
6-1 Jaw Case Front
6-2 Jaw Case Back
7 Jaw
8 Jaw Pusher
9 Case Washer
10 Jaw Pusher Spring
10A Housing Cap O-Ring (Ø27 x 2)
11 Head
12 Case Lock Nut
13 Back Up Ring
14 Back Up O-Ring (Ø12)
15 Housing
16 Hydraulic Piston
17 Hydraulic Piston O-Ring (Ø22A)
18 Back Up Ring
19 Return Spring
20 Hanging Ring
21 Housing Cap
22 Pin Cap Nut
23 Pin Cap
24 Set Screw Pin
25 Back Up O-Ring (Ø12)
26 Back Up Ring
27 Housing Lock Nut
28 Rubber Cushion
Part Description
29 Air Cylinder
30-1 Air Piston Stem
30-2 Air Piston Insert
30-3 Air Piston Lock Nut
30-4 Large Iron Plate
30-5 Small Iron Plate
31A Air Piston Ring
32 Cylinder O-Ring (Ø67.94 x 2.62)
33 Cylinder Cap
35 Wrench Gauge
36 Wrench
37 Trigger Pin
38 Connector
39 Trigger Rod
40 Trigger
41 Connector
42 Trigger Lever
43 Lever Pin
43A Valve Pusher O-Ring (Ø7)
44 Valve Pusher
44A Pusher Spring
45 Valve
45A Valve Collar
45B Collar O-Ring (Ø5)
46 Valve Spring
51 Valve Cap O-Ring (Ø11)
52 Valve Cap
53 Quick Connector (not shown)
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Record Product's Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
