Page 6 For technical questions, please call 1-888-866-5797. Item 93458
Functional Description
Specifications
Maximum Air Pressure 90 PSI
Air Inlet 1/4″ -18 NPT
Average Air Consumption 3 CFM @ 90 PSI
Rivet Pin Capacity
3/32″, 1/8″, 5/32″, 3/16″
(Nosepiece change needed)
Maximum Pull Force 2,800 lb.
Components and Controls
Nosepiece
(1A, 1B, 1C, 1D)
Head (11)
Pin Cap (23)
Trigger (40)
Pin Cap
Nut (22)
Quick Connector (53)
SAFETY OPERATION MAINTENANCESETUP
