Page 14 H&(%$*4.8"4,7%G'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1 Item 95810
NOTICE
Clean the Spray Gun IMMEDIATELY after use.
Delayed or inadequate cleaning will permanently clog the Spray Gun.
D=H6BC QR6S=B?Q> @=?>B6>=>;6D6BTR
F*8*(,7%B(&'+7*#.&&$"83%;.,($
R(&+7*5 R&##"+7*%;,'#*# <"Z*7E%D&7'$"&8#
Sputtering Spray 1. Low paint level.
2. Jar tipped.
1. Refill.
2. Hold upright.
Will Not Spray 1. No pressure at Airbrush.
2. Fluid too thick.
1. Check air hoses.
2. Thin fluid or increase air pressure.
(Do not exceed maximum.)
Overspray
(Paint drifting
to unintended
objects.)
1. Improper application speed.
2. Improper distance from workpiece.
3. Too much air pressure.
1. Move moderately and parallel.
2. Adjust distance.
3. Reduce air pressure.
Poor atomization
of paint
1. Air connection not tight, or leaking.
2. Paint not thinned properly.
3. Nozzle (3) is partially plugged
1. Check all air connections.
2. Add more solvent in very small
amounts to the paint you are
using and mix thoroughly.
3. Wash, or change the Nozzle (3)
H&77&)%,77%#,2*$E%/(*4,'$"&8#%).*8*[*(%9",38&#"83%&(%#*(["4"83%$.*%$&&71%%%
A"#4&88*4$%,"(%#'//7E%+*2&(*%#*(["4*1
R<6=D6%S6=A%BX6%HQ<<QU?>F%;=S6HT<<C
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND
ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE
MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY
OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS
TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF
THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN
BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE
BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS
TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
