CENTRAL ROC - Page 3

Figure 3
Residential Optima Concealed Pendent (Activated)
Figure 2
Residential Optima Concealed Pendent (Non-Activated)
2-1/2" ±1/8"
(63,5 mm ± 3,2 mm)
Hole Diameter
Face of Reducing Coupling
Reducing Coupling
3-1/4" (82,6 mm) Diameter
3/16" (4,8 mm)
2" ±1/4"
(50,8 mm ± 6,4 mm)
3/8" (9,5 mm)
(ref.)
2-9/16" to 3-1/16"
(65,1 mm to 77,8 mm)
5/8" (15,9 mm) Min.
1-1/8" (28,6 mm) Max.
