Page 18 For technical questions, please call 1-800-444-3353. Item 68019
SAFETY OPERATION MAINTENANCESETUP
Parts List and Diagram
Parts List
Part Description Qty
1 Socket Head Screw (M5x.80x20mm) 6
2 Spring Washer 6
3 Air Deflector 1
4 Cylinder Cap 1
5 Sealing Washer 1
6 Exhaust Plate 1
7 O-Ring 1
8 O-Ring 1
9 Head Valve Spring 1
10 Head Valve 1
11 O-Ring 1
12 O-Ring 1
13 O-Ring 1
14 Cylinder Cap Sealing Ring 1
15 Collar 1
16 Sealing Ring 1
17 Cylinder 1
18 O-Ring 1
19 O-Ring 1
20 Piston Assembly 1
21 Bumper 1
22 Housing 1
23 Sealing Gasket 1
24 Safety Spring 1
25 Push Stem 1
26 Safety 1
27 Guide Sleeve 1
28 Socket Head Screw (M4x.70x10mm) 4
29 Rectangle Gasket 1
30 Valve Seat 1
31 O-Ring 2
32 Valve Stem 1
33 O-Ring 1
34 Valve Sleeve 1
35 Valve Spring 1
36 Trigger 1
Part Description Qty
37 Position Pin 1
38 Safety Plate 1
39 Pin 1
40 Drive Guide 1
41 Fixed Plate 1
42 Movable Plate 1
43 Pin 1
44 Quick Release Lever 1
45 Quick Release Spring 1
46 Pin 1
47 Position Spring 1
48 Spring Plate 1
49 Pin 1
50 Magazine Bolt 2
51 Pin 1
52 Fixed Magazine 1
53 Insert Bar 1
54 Position Seat 1
55 Movable Magazine 1
56 Pin 1
57 Locking Piece 4
58 Magazine Guide Bar 1
59 Socket Head Screw 4
60 Pusher 1
61 Pusher Stem 2
62 Pusher Spring 2
63 Pin 1
64 Latch 1
65 Latch Spring 1
66 Grip 1
67 O-Ring 1
68 Air Inlet Cap 1
69 Air Inlet Plug 1
70 Plug Cap 1
71 Pin 1
72 Socket Head Screw (M4x.70x10mm) 1
