Page 14 For technical questions, please call 1-800-444-3353. Item 68020
Parts List and Diagram
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Part Description
1 Screw
2 Flat Gasket
3 Air Deflector
4 Deflector Washer
5 Hex Bolt
6 Spring Washer
7 Cylinder Cap
8 Head Valve Spring
9 Head Valve Seat
10 O-Ring
11 O-Ring
12 Head Valve Assembly
13 Collar
14 O-Ring
15 Collar
16 O-Ring
17 Cylinder Sealing Ring
18 Cylinder
19 O-Ring
20 Piston Assembly
21 Bumper
22 Cylinder Cap Washer
23 Housing
24 Guide Gasket
25 O-Ring
26 O-Ring
27 Valve Seat
28 O-Ring
29 O-Ring
Part Description
30 O-Ring
31 Valve Sleeve
32 O-Ring
33 Valve Spring
34 Valve Stem
35 O-Ring
36 Valve Seat
37 Trigger Spring
38 Pin
39 Safety Plate
40 Trigger Pin
41 Trigger
42 O-Ring
43 Guide Frame Assembly
44 Locking Nut
45 Adjusting Nut
46 Steel Ball
47 Thrust Spring
48 Pin
49 WCE Spring
50 WCE Assembly
51 Guide Gasket
52 Retainer
53 Safety Spring
54 Yoke
55 Safety Nosepiece
56 Hex Bolt
57 Retainer
58 Hex Bolt
Part Description
59 Gasket
60 Fixed Plate
61 Hex Bolt
62 Quick Release Assembly
63 Quick Release Cover
64 Cover Pin
65 Position Pin
66 Drive Guide
67 Spacer
68 Hex Bolt
69 Spring Pin
70 Magazine
71 Hex Bolt
72 Position Seat
73 Spring
74 Pusher Pin
75 Pusher
76 Coiling Spring
77 Slider
78 Pin Sleeve
79 Nail Guide Bar
80 Grip
81 End Cap Gasket
82 End Cap
83 Spring Gasket
84 Hex Bolt
85 Air Inlet
86 Plug cap
