Continuous Operation
Many people use their computers continuously, without ever turning
them off. You could do the same with DACmini, if you prefer. There is
no harm in leaving your DACmini on for an extended amount of time.
DACmini power consumption of is comparable to that of a small laptop.
Specifications
Electrical Characteristics
Line output section Line Input Digital Input
Maximum Output +20dBV +6.2dBV
Nominal Output +6.0dBV +6.2dBV
Frequency Response, 10Hz - 20kHz +0,0dB -0.1dB +0.0dB, -0.15dB
Noise Floor: (A-weighted) -124 dBV -107 dBV
S/N Ratio: (A-weighted) 144dB 113dB
THD+N 0.00022% 0.001%
Crosstalk -128dB 118dB
Output Impedance: 25 Ohms
Headphone section Line Input Digital Input
Max Output
1
, 32Ω load, typical +13.5dBV +11.8dBV
Max Output
1
, 300Ω load, typical +18.6dBV +14.1dBV
Max Output
1
, 600Ω load, typical +19.0dBV +14.2dBV
Output Impedance: 10 Ohm
2
1
Specified for reference -- to be used with low-sensitivity headphones only. Listening to
IEMs or other high sensitivity headphones at this level may damage your hearing.
2
This value is chosen as a dynamic and musical setting. However, a custom mod is
available to make the output impedance 1 Ohm. Check with CEntrance.
Physical Characteristics
Product size: 164mm x 164mm x 42mm
Product weight: 950 g
Shipping box size: 380 mm x 260 mm x 80 mm
Shipping box weight: 1.7 kg
Warranty
- 14 -
1 year from the date of purchase. No user-serviceable parts inside.
Contact CEntrance if you need service and we will do our best to help.
