SECTION 3 ELECTRICAL SETUP
Check that the charger and battery are connected to the Controller.
Ensure that the battery polarity is correct.
FIGURE 4
Charger
FIGURE 5
Battery
Switch on the mains supply (via isolator).
EnsurethatboththeControllerandchargerareeectivelyearthedforimprovedlightning
protection.
