IVA-22
Section IVA - OPERATING INSTRUCTIONS
WHEEL LIFT (cont'd)
4A.10 TOW BALL (OPTIONAL) (cont'd)
FIGURE 4A.25
(d) Fully retract wheel lift boom to prevent crossbar from pivoting,
then raise wheel lift to desired height for towing.
(e) Attach safety chains.
NOTE
THE PURPOSE OF USING THE WHEEL LIFT FOR TOW BALL
APPLICATION IS FOR ITS EASE OF OPERATION USING A
MINIMUM OF MANUAL ALIGNMENT.
4A.13 OUTER CROSSTUBE REMOVAL
(a) Fully extend outer crosstubes, then push back on approximately
1/2".
(b) Using a screwdriver or 1/4" rod, insert into crosstube removal
hole located beside "T" handle. See Figure 4A.26.
