IVA-27
Section IVA - OPERATING INSTRUCTIONS
WHEEL LIFT (cont'd)
4A.12 TOW FORK & ADAPTER APPLICATIONS (cont'd)
FIGURE 4A.30
(i) Raise vehicle to desired height for towing.
(j) Remove any blocks previously placed under the tires.
(k) Retract wheel lift boom pulling disabled vehicle as close to the
wrecker body as possible, while maintaining enough distance
for sharp turns.
(l) Raise wheel lift boom to desired towing height.
(m) Pull excess safety chain back into storage caddy. Be certain to
allow enough slack for sharp turns.
USE SAFETY CHAINS ON ALL TOWING
AND LIFTING APPLICATIONS!
