This document is a user manual for the CEPTER All-in-one Computer, model CFUSION24I3. It provides instructions and technical specifications in multiple languages, including English, Norwegian, Danish, Finnish, and Swedish.

Function Description:

The CEPTER CFUSION24I3 is an all-in-one computer, meaning the computer components are integrated into the display unit, offering a compact and streamlined design. It is designed for general computing tasks, including internet browsing, media consumption, and productivity applications. The device includes a built-in webcam for video calls and a range of ports for connecting peripherals and external displays.

Important Technical Specifications:

Model Number: CFUSION24I3
Screen Size: 23.8 inches
Aspect Ratio: 16:9
Resolution: 1920 × 1080 (Full HD)
CPU: Intel Core i3-1005G1
GPU: Intel UHD Graphics
Memory: 8GB RAM + 256GB SSD
Wireless Connectivity:
- WiFi: 802.11ac/b/g/n
- Bluetooth: BT 5.1
Camera: 3.0MP (Webcam)
Operating System: Windows 11 Home
Power Input: 100-240V~50/60Hz 1.5A
Power Output: 19V/4.74A 90.06W
Interfaces (Rear View):
- External DC Power Interface (19V)
- HDMI OUT (External Signal Output for external displays)
- Ultra-fast Ethernet Interface (LAN)
- USB 3.0/USB 2.0 Interface (for USB devices)
- Microphone Interface
- Audio Output Interface (for headphones or 2.0-channel audio output devices)
- DP (DisplayPort) External Signal Output

Usage Features:

The computer is designed for ease of use with a straightforward setup process.

Appearance and Front View: The front features the 23.8-inch display screen, an aluminum alloy bracket for support, and a webcam located at the top of the display.
Pack Contents: The package includes the main body of the all-in-one computer, a keyboard, a mouse, and a power adapter.
Bracket Installation: The manual provides clear steps for installing the bracket:
1. Remove the base screw and lock the base to the bracket with the screw.
2. Insert the top two clasps of the bracket into the corresponding card holes on the machine and press the bracket downward to secure it.
Power Connection:
1. Connect the power adapter to the power cord.
2. Connect the power adapter to the corresponding interface on the back of the computer.
3. Connect the power cord to a properly grounded power outlet.
Peripheral Connection: The USB keyboard and mouse are connected to the USB interface on the computer.
System Startup: After ensuring all connections are correct, the computer is turned on by pressing the power button on the back panel.
Display Settings: Users can adjust display attributes like background, icons, resolution, and orientation through the display settings, accessed by right-clicking on the desktop.
Internet Connectivity: The manual explains how to connect to the internet via broadband (PPPoE) or by setting up a new network connection.
Wireless Connection Management: Instructions are provided for establishing and deleting wireless network connections.

Maintenance Features:

The manual includes a "Frequently Asked Questions (FAQ) and Attentions" section to help users troubleshoot common issues, which can be considered a form of user-level maintenance.

Troubleshooting Display Issues:
- Water Ripples on Screen: If water ripples appear on the screen, users are advised to check for nearby devices (refrigerators, electric fans, hair dryers, UPS, voltage stabilizers, fluorescent lamps) within 1 meter that might cause magnetic field interference. If two computer screens are too close, ripples may appear on both; moving the interfering device away is the suggested solution.
- Black Screen/No Image: Users should verify if the computer is powered on and check power connections and cable integrity. If the issue persists after basic checks, contacting after-sales service is recommended.
Troubleshooting Audio Issues: If there is no sound from external audio devices (speakers, headphones), users should check if the sound is muted or turned down in the volume settings. Reinstalling the audio driver might be necessary if the volume cannot be adjusted.
Troubleshooting Webcam Issues: The pre-installed camera driver should work without additional installations. Users are advised to check if the camera is turned on or if it's being used by other video applications if it's not functioning.
Troubleshooting Startup Issues (No Sound/No Image):
- If the power button is pressed but no startup sound is heard, users should check the household power line, power adapter connection, and power outlet. A specific sequence of pressing the power button 5 times during a power outage is suggested before reconnecting and restarting.
- If a startup sound is heard but no image appears, users should press the power button for 5 seconds to shut down, then check power supply and all cable connections as described in the manual. If the issue remains, after-sales service should be contacted.
Transporting the Computer: When moving the computer, users are instructed to grasp or hold its body tightly and firmly before lifting or putting it down to prevent damage.

The manual also includes information regarding WEEE recycling regulations and contact details for Power International AS and its local branches for support in Norway, Denmark, Finland, and Sweden.
