Ceridian Dayforce Tuff Clock - Page 11

DF Tuff
Page 11 of 31
Step 3: Attach battery extension cable to battery as shown in Figure B3.
Ensure connectors are attached in the correct orientation.
Figure B3: Attaching battery extension cable to battery.
Step 4: Attach battery extension cable to main circuit board as shown in
Figure B5. Ensure that the connectors are attached in the correct
orientation.
