Cervis Wireless Smart HH 10 Series User Manual

Remote Control Unit Manual
2019 Cervis, Inc.
9
6.0 Specifications
Table 2. SmaRT HH-x10 Remote Control Unit Specifications
Item
Description
Power
V
in
+2.1V to +3.2VDC
Source Two AAA cell batteries
Auto-shutdown Four minutes of button inactivity (default)
Low Battery Warning ≈2.1V – batteries should be immediately replaced
Low Battery Shutdown 2.0V – batteries must be replaced to operate
Environment
Operating Temp -20°C to 55°C (-4°F to 131°F)
Storage Temp -40°C to 55°C (-40°F to 131°F)
Humidity 0 to 100%
Radio
Frequency 906–924MHz @ 10mW (HH-9H10)
906–924MHz @ 100mW (HH-9X10)
2405–2480MHz @ 100mW (HH-2H10)
License None required
Modulation DSSS
Antenna Internal
Enclosure
Dimensions mm: 136.38 x 68.96 x 28.42
inches: 5.37 x 2.68 x 0.92
Total Weight 200g/7.2 oz. (with lanyard or belt clip)
Durability High Impact Polymer case
Polycarbonate faceplate
Impact absorbing bumper
LED
Indicators
TX (Green) Transmit – Flashes when transmitting messages
RX (Amber) Receive – Flashes when receiving messages
ER (Red) Flashes when errors are detected
BAT (Amber) Blinks when low battery condition exists
A1 Used when custom-programmed
A2 Used when custom-programmed
Buttons
Twelve Pushbuttons
Number of Functions Ten to twenty, program-dependent
