Model SDI-50 Manual. Repeater Controller

PROGRAM

CODE DESCRIPTION FACTORY SETTING CHANGED TO

40 Mute on Pulse Dial on ___________

41 Begin Overdial w/"*" off ___________

42 Begin Overdial w/"#" off ___________

43 Phone in Use on ___________

47 DTMF Regenerate on ___________

Remote programming code 975310#

Control Codes

0 Connect/Disconnect Codes *73/#73 ___________

1 Special Connect Code *37 ___________

ON OFF

2 Control Function #1 Code *14 *04 ___________

3 Control Function #2 code *25 *15 ___________

4 Interconnect Enable Code *36 *26 ___________

5 Repeat Enable Code *38

28 ___________

Dial-up Remote Code 8421# ___________

Messages

0 Connect Message “ON” ___________

1 Disconnect Message “OFF” ___________

2 Time out Message “TO” ___________

3 Error/Signal Message “EEEEEEEE” ___________

4 Station I.D. Message “RING” ___________

Note 1 - For repeater operation, *5 23 shouid be turned on and *5 14

should be turned off. When *5 14 is on, the patch is in simplex

mode and *5 23, and *5 24 are used to modify the sample rate.

Note 2 - This is a two part switch. The following switch number must

also be set. Refer to the section in the manual for more detall

on setting these.

Note 3 - Switches 23 and 24 have different uses for simplex and duplex

operation. If switch 14 is on and 36 is off, then 23 and 24

are used to adjust the sample rate for simplex use. If 14 is

off, and 36 is on, then 23 is used for "Repeat Enable" and 24

is for "Courtesy Beep" during dúplex use.

NOTES:________________________________________________________________

______________________________________________________________________

Page # 41
