Product details
Product guide – CESAB S200
55
Stepless control with continuously adjustable lifting/lowering control
All models, except S208L and S210, can be optionally tted with stepless control
for the lift and lowering movement. Stepless control comes with an analogue con-
trol with continuous adjustment possibility.
Feature
The design with continuous adjustment enables
highly precise control of pump motor revs and
the proportional valve, which are used to control
lifting and lowering movement.
Benet
This enables gentle, precise positioning of load
carrier with no recoil effect.
Feature
The continuous adjustment design of the control
requires little effort to operate, while the control is
easy to use with both hands.
Benet
The operator can fully concentrate on the load and
fork positioning.
Creep speed for lifting and lowering
Creep speed applied to lifting/lowering movement operates similarly to creep
speed during truck travel. To activate the creep lift/lowering speed the operator just
needs to make a quick stop in the lifting/lowering movement and then continue.
The actual speed used during low-speed operation can be programmed by a ser-
vice technician. To disengage the mode, simply click the control once more. This
feature is available on all models, however on the S210 and S208L it only controls
lowering movement, while trucks tted with stepless control completely lack this
feature , since there’s no need for it if you can control the lifting/lowering speed
steplessly. If required, Creep speed of lifting/lowering movement can be disabled
by a service technician.
