Performance, Weight & Balance
Cessna 172s V speeds.
Speeds listed below are in Knots Indicated Airspeed (KIAS).
Weight and Balance.
Formulas
Weight × Arm = Moment
Total Moment ÷ Total Weight = CG
Max Ramp Weight – Zero Fuel Weight = Usable Fuel Weight
Fuel Weight ÷ 6 = Fuel Gallons
100 LL (Blue) Fuel Weighs 6 lbs./gal.; Oil Weighs 7.5 lbs./gal.
Unusable fuel and oil at full capacity are Included in Basic Empty Weight
Maximum Ramp Weight 2558lbs
Maximum Take off weight weight 2550lbs
Speed
KTS
Description
Airspeed indicator markings
40
Stall speed in landing configuration
48
Stall speed with zero flaps
Bottom of White Line
55
Rotation speed (start rotation)
Bottom of Green Line
62
Best angle of climb
74
Best rate of climb
68
Best glide speed
110
Maximum flap 10 degrees speed
85
Maximum flap 20-FULL degrees speed
Top of White Line
129
Max Structural Cruising Speed
Top of Green Line
163
Never exceed speed
Red Line
105
Maneuvering speed
