CESSNA 337 SKYMASTER Instruction Manual.
12
2) Use a pin drill and 2mm drill bit to drill a
small indentation in the mount for the engine
mounting screw.
105mm.
MOUNTING THE ENGINE BEFORE.
1) Position the engine with the drive washer
(110mm) forward of the firewall as shown.
Trim and cut.
Switch.
rudder servo arm.
Rudder servo arm.
Elevator servo arm.
INSTALLING THE SWITCH.
3/ 32” Hole.
Install the switch into the precut hole in the
side, in the fuselage.
Throttle servo arm.
Landing gear servo arm.
To Next Page
