Cetron JEC1758 - Page 82

82
317B8267P001 Wiring Diagram
(See features by model chart, at the end of the manual.)
WARNING: DISCONNECT THIS APPLIANCE FROM POWER
SOURCE BEFORE PERFORMING ANY TYPE OF SERVICE.
PARA OBTENER LA CLASIFICACIÓN
ELÉCTRICA, REFIÉRASE A LA PLACA
DE IDENTIFICACIÓN
TO OBTAIN THE ELECTRICAL
RATING, REFER TO
IDENTIFICATION PLATE
INTERRUPTOR LUZ HORNO/
OVEN LIGHT SWITCH
OX
VX
L
MÓDULO DE
IGNICIÓN/
IGNITION MODULE
N
RX
RX
INTERRUPTOR BUJÍA/
SPARK SWITCH
LUZ HORNO/
OVEN LIGHT
WX
WX
QUEMADORES
SUPERIORES/
COOKTOP BURNERS
RX/WX
RX/WX
RX/WX
RX/WX
RX/WX
RX/WX
WX
L N
HORNO/OVEN
ROJO/RED
BLANCO/WHITE
NARANJA/ORANGE
VIOLETA/VIOLET
COLOR
RX
WX
OX
VX
SÍMBOLO/
SYMBOL
ALGUNOS MODELOS/
NOT IN ALL MODELS
