CF MOTO CF400ATR-2S User Manual

MAINTENANCE & LUBRICATION
121
Front access cover
Removal:
Grasp the access cover edge, pull upward to release the
grommet pins, then remove the front access cover
A
by
direction of front of vehicle.
Install:
Insert the cover tabs into the corresponding holes on
the body, then align the grommet pins and press down.
NOTE:
Remove front access cover, then inspection and maintenance
can be done for the radiator assy, reservoir tank, relay box, and
fuse.
A
