149
MAINTENANCE
Engine oil maintenance- 1000 engine only
NOTE:
The 1000 engine has separate engine and transmission oil drain
/ ll locations. It also has an internal sump strainer behind a cover
that can be checked and cleaned during an oil change.
Oil level check (1000)
1. Place the vehicle on a level surface.
2. If the engine was running, wait a sucient amount of time for
the oil to settle and cool.
3. Unscrew the crankcase Oil dipstick
2
, remove it, and wipe o
with a clean cloth.
4. Insert the dipstick back into the dipstick hole, make the dipstick
threads contact the hole surface without screwing it.
5. Remove the dipstick and check the oil level indication. Maintain
the oil level between the upper and lower indicators.
6. Reinstall the dipstick into the oil ller hole, and hand-tighten it.
Oil and lter change (1000)
1. Place the vehicle on a level surface.
2. If the engine was running, wait a sucient amount of time for
the oil to settle and cool.
3. Place an oil pan under the engine to collect the used oil.
2
MAX
MIN
1000 Engine
Oil Dipstick
Location
