CGC IKV008 - Weight;Dimension;Clearances

HybridVerticalStack–InstallationOperationMaintenanceManual


INFORMATION

R090303InstallationOperationMaintenanceManualissubjecttochangewithoutnotice Page2
5. Theindividualunitsshallnotbestackedontopofoneanother.
6. Iftheunitwaspreviouslyinuse,ensurethatallwaterinthecoilhasbeenblownoutand
thatallhoseconnectionsarepluggedduringstorage.
Weight/Dimension/Clearance
UnitWeight:

Model 008 010 012 015 018 020 024 030 036
Weight
(lb)
115 120 120 135 145 210 225 225 240

UnitDimension:

Models008‐018

Models020‐036



UnitClearance:

Theverticalstackproducthasasound‐dampeningfrontcoverpanelandreturnairboot.The
sound‐dampeningpanelslidesoffwithminimalserviceclearance,however,intheeventof
chassisreplacementthefrontserviceentrancemustpermitstraighthorizontalremovalofthe
chassis.Thereturnairbootmustbeunobstructedduringoperation.
Theinstallationofallverticalstackproductandcomponentsandaccessoriesmustbein
accordancewithalllocalcodeandregulationsofallgoverningauthoritieshavingjurisdiction.
Themanufacturerrecommendsthefollowinginstallationprocedures.Itistheresponsibilityof
theinstallingcontractortocomplywithallapplicablecodesandregulations.
Figure1
Figure2
