DeviceOverview
BluetoothDongle
High-speed receiver
dongle plugs into
your computer’s
USB port.
Amplifier
Wireless amplier
collects signals
and transmits to
Bluetooth Dongle.
FlexSensor
Flex sensors slide
through hair for
high-quality scalp
contact.
DrypadSensor
Drypad sensors
make direct
skin contact for
ECG and EEG
recordings.
A1Earclip
A1 left ear
earclip has two
sensor locations:
Reference and
Ground.
A2Earclip
A2 right ear earclip
is used in linked-
ears congurations.
DrypadEarSensor
Dedicated Drypad
sensors for use with
Earclips.
LeadWires
Active lead wire
(3.5mm connector)
for Reference/A1
and A2.
Passive lead
wire (touchproof
connector) for
Ground and ExG.
Active Passive
