9
Preparation
8.StartTheAcquisitionSoftware
Once you’ve established a connection, data should begin
to stream.
Double click on the CGX Acquisition software icon. You
should see CGXQuick-32runder DiscoveredDevices.
If you do not see the name CGX Quick-32r, remove
and re-insert the dongle and restart the software.
1. First, click the device name in this window to select the
Quick-32r.
2. Then click Connect.
You should now see the device conguration window.
If you do not, double check to make sure the
Quick-32r is powered on.
Click StartDevice.
You will now see data streaming into the display. Click the
Channels tab on the top right-hand side of the program.
This will bring you to the impedance check. You are now
ready to use the device.
Each Quick-32r is permanently paired to a receiver dongle.
The pair automatically discover and initiate a connection
when both are powered on and within a 10m range.
The light on the dongle indicates its current state:
Dongle
Indicator light
