Chainway C6000 - Data Collection Engine Specs

FDD-LTE: Band1/3.
WLAN
IEEE802.11 a/b/g/n, internal antenna
WPAN
Bluetooth v4.0
Data Collection
1D Barcode Scan Engine
1D barcode（Symbol SE955, laser, hardware decoding）:
UPC/EAN, Code128, Code39, Code93, Code11, Interleaved 2 of
5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, ect
2D barcode（Symbol SE4500，COMS, software decoding）：
Data Matrix, QR Code, Aztec Code, PDF417, US Planet, UK
Postal, ect.
2D Barcode Scan Engine
2D CMOS laser scanner: Symbol SE4500
Sensor resolution: 750 (horizontal ) * 480 (perpendicular) pixel
(gray level)
Roll tolerance: 360º
Pitch tolerance: ±60º
Skew tolerance: ±60º
Ambient light: 9000ft.candles/96900 lux (lightless)
Aiming LED (VLD): 655nm ± 10nm
Illumination element: 650nm ± 5nm
Field of view: 40º horizontal，25º perpendicular
Barcode type: PDF417, MicroPDF417, Composite, RSS, TLC-39,
Datamatrix, QR code, Micro QR code, Aztec, MaxiCode; Postal
