4.0 Specifications
7
4.0 Specifications
Description Inch Units Metric Units
Drill Head Operation, Hand Lever
Drill Diameters 13 sizes from 1/8” to ½” 3-13mm
Lift Capacity 2” for drills ¼” or larger 51mm
Minimum Distance Btw. Holes 3/8” center to center 10mm
With Fixed Gages ¼” center to center 6mm
Maximum Distance Drill to Side
Guide
12” 30cm
Maximum Margin Hole Center to
Sheet Edge
2-3/4” 7cm
Cornering Attachments ½” capacity light duty
Slitting/Slotting ½” capacity light duty
Side Guide Trip Manual
Dimensions
Net Weight 50 lbs. 31kg
Table Space 18” x 27” 46 x 69cm
Height Overall 27” 68.6cm
Electrical
115 Volts, 5.4 Amps, 60Hz, 1 phase, AC.
Challenge reserves the right to make changes to any product or specification without notice and
without incurring responsibility to existing units.
