A-10 - GENERAL INFORMATION
79019435B
Power take-off (PTO)
Control Electric switch
Clutch Wet, multi-disc, hydraulic
Rear PTO shaft 35 mm (1.378 in) diameter - six spline
Output Clockwise rotation (Facing shaft)
Speeds @ engine rpm Hydro-540 @ 2680 / STD-540@2730
Mid PTO (accessory) shaft 25 mm (1 in) diameter - fifteen spline
Output Clockwise rotation (Facing shaft)
Speeds @ engine rpm Hydro-2000 @ 2583 / STD-2000 @ 2698
Hydraulics
Main hydraulic system
Pump Gear pump (Open center)
Output – maximum 20.2 liters/min 5.28 USGPM
Pressure - relief valve setting 140 kgf/cm
2
/ 1991 psi
Rear linkage type Three-point hitch
Control Operated by single ‘position’ control lever
Lift capacity 550 kg / 1210 lbs measured at link ends
Steering system type Hydrostatic
Pump Gear
Output – maximum 10.0 liters/m (2.6 USGPM)
Pressure - relief valve setting 105 kfg/cm2 (1493 psi)
