GENERAL INFORMATION - A-9
79019435B
SPECIFICATIONS
Models 1423 / ST25 / MT225
Engine
Make ISEKI Diesel
Model E3112-B05
Type Indirect injection, overhead valve
Displacement 1123 cc/68.5 cu.in.
Number of cylinders 3
Bore 78.2 mm/3.078”
Stroke 78 mm/3.070”
Engine horsepower (net) @ engine rpm 16.5kW (22.5hp)/2800
Firing order 1 - 3 – 2
Compression ratio 22.5:1
Low idle speed 950 rpm
High idle speed 3050 rpm
Valve clearance (cold) - intake and exhaust 0.25 mm / .010”
Air cleaner Single - dry element
Engine cooling Liquid, forced circulation
Cold starting Glow plugs (3)
Transmission
Hydro Standard
Primary Infinite 3
Range 2 2
Gear selections F2/R2 F6/R2
Brakes Mechanically actuated dry shoe
