DANGER:
Diesel fuel or hydraulic fluid under pressure can penetrate the skin or eyes. This can cause
serious personal injury, blindness, or death.
1.1.25 Fluid penetration
Always use a board or cardboard when checking
for a leak. Leaking fluid under pressure can
penetrate the body tissue. Fluid penetration can
cause serious injury and possible death. A pin hole
leak can cause severe injury. If fluid is injected into
the skin, get treatment immediately. Get
treatment from a doctor familiar with this type of
injury.
Check the lines, the tubes and the hoses carefully.
Do not use your bare hand instead, use a board or
cardboard to check for leaks. Tighten all
connections to the recommended torque.
Replace the hose if any of the following conditions
are present:
•
End fittings are damaged or leaking.
• Outer coverings are rubbed or cut.
• Wires are showing.
• Outer coverings are ballooning.
• The flexible part of the hose has a kink.
• Outer coverings have embedded armoring.
• The end fittings are displaced.
IMPORTANT: Take care to contain fluids during
the performance of the inspection, the
maintenance, the testing, the adjusting, and the
repair of the machine. Have a suitable container
large enough ready to collect the fluid before
opening any compartment or disassembling any
component containing fluids. See the local
regulations and mandates when discarding fluids.
GUID-9A83C5CD-95EC-445B-A3A7-1DCF8FACFE45-high.jpg [High]
Fig. 12
1.1.26 Exhaust fumes
Always work in a correct ventilated area.
Engine exhaust fumes can cause sickness or
death. If necessary to run engine in a closed area,
use correct equipment to safely remove exhaust
fumes from area.
Always open the doors and get outside air into
area.
GUID-14D1976F-1E03-40BF-8B7E-EBFFE3E03995-high.jpg [High]
Fig. 13
GUID-E76BB0CD-67F0-40CD-A4CC-D6B27E9CDCCE [V2]
GUID-7F41C7C3-DACC-46D2-ADC7-531D148964D3 [V2]
1. Safety
22 Articulated Tractor
582773D1C
