4 . MAINTENANCE AND ADJUSTMENTS
4.38
Challenger MT500B EU
• One of the two error codes is displayed on the left-hand
screen (DOT MATRIX) (Fig. 82).
• Position the limp home lever on the control (Ref. 1) (Fig.
83).
• Turn the lever in the required direction of travel:
- anti-clockwise direction, forward travel,
- Clockwise, reverse travel.
NOTE: Travel speed depends on the rotational value of
the lever.
• Carefully release the clutch pedal. The tractor moves in
the previously set direction of travel and manually
reaches the selected ratio.
• To deactivate the limp home mode, stop the tractor and
switch off the ignition key.
ERROR
Code TLPH
ERROR
Code 4159
Fig. 82
Z2-611-07-03
Fig. 83
Z2-612-07-03
1
2
