Hardware

ASSEMBLY INSTALLATION

DOOR CONTROL

Insulated Staples

(Not

Shown)

Bolt

1/4"-20x1-3/4"

Lock Nut

1/4"-20

Bolt

Nut 3/8" Lock Washer 3/8"

Master Link (2)

Threaded

Shaft

Clevis Pin 5/16"x1-1/2"

Ring

Fastener (3)

Hex Bolt 5/16"-18x7/8" (4)

Lock Washer

5/16"-18 (5)

Nut

5/16"-18 (6)

Self-Threading Screw

1/4"-14x5/8" (2)

Clevis Pin 5/16"x1" Clevis Pin 5/16"x1-1/4"

Carriage Bolt

1/4"-20x1/2" (2)

Wing Nut

1/4"-20 (2)

Lag Screw 5/16"-9x1-5/8" (4)

Screw

6ABx1" (2)

Screw

6ABx1-1/2" (2)

Drywall

Anchors (2)

Screw

6-32x1" (2)
