Chamberlain Merlin MT60P - Door Types, Tools, and Hardware

DOOR TYPES
1
TOOLS REQUIRED
HARDWARE PROVIDED
Installation Hardware:
(4) Large Clevis Pin (1)
(5) Carriage Bolts (2)
(6) Wood Screws (4)
(7) Clevis Pins (medium) (2)
(8) Hex Screws (4)
(9) Rope
(10) Handle
(11) Lock Washers (6)
(12) Nuts (6)
(13) 4mm Anchors (2)
(14) R-Clip (4)
(15) 8mm Anchors (4)
(16) Sheet Metal Screw (4)
4
9
8
5
6
7
13
12
11
15
10
N
O
T
I
C
E
16
14
2
3
2
A
. One-Piece Door with Horizontal Track
Only
B. Sectional Door with curved track
C
. One-Piece Door without track
T
o suit spring balanced sectional
doors up to 12.5m
2
o
r
spring balanced Tilt doors up to
8.5m
2
.
A
B
C
2
1
10mm,8mm,
4.5mm,4mm
11mm,13mm
8mm hex
head driver
