Champion 100261 - Generator Controls and Features Overview; Generator Components Identification

5
ENGLISH 100261
Read this owner’s manual before operating your generator. Familiarize yourself with the location and function of the
controls and features. Save this manual for future reference.
(1) Fuel Cap – Remove to add fuel.
(2) Recoil Starter – Used to start the engine.
(3) Power Panel
(4) Foldaway Handle – Do not use the foldaway handle
to lift or carry the unit.
(5) Muffler
(6) Carrying Handle
(7) Maintenance Cover
(8) Never Flat Wheels
(9) Battery Access Cover
Generator
CONTROLS AND FEATURES
Parts Included
Your 100261 gasoline powered generator ships with the
following parts:
– Dual 2.4A Port USB Adapter . ............... 1
– Oil funnel . ............................ 1
– Remote .............................. 1
637
637
7 98
6
637 440
464
3 4
5
2
1
