Champion 64 PRO - Rinse Arms

25
Cleaning
RINSE ARMS — The upper and lower rinse arm nozzles should be cleaned regularly
to prevent scale build-up.
ROTATE RINSE ARM 1/4 TURN AND PULL TO REMOVE (FIG. 35).
USE SCREWDRIVER TO REMOVE END PLUG AND FLUSH ARM WITH
CLEAN WATER. INSPECT O-RING FOR DAMAGE AND REPLACE IF
NEEDED (FIG. 36).
CLEAN THE SPRAY NOZZLES WITH A PAPER CLIP (FIG. 37).
1
2
3
Fig. 35
Fig. 36 Fig. 37
