To Next PageTo Next PageWhat to do if my Champion UL130 Dishwasher won't run?
If your Champion Dishwasher won't run, the door may not be completely closed, the main power could be off, or the dishwasher itself might be turned off. Ensure the door is completely closed, check the breaker on the panel, and turn the dishwasher power switch on.
What to do if my Champion Dishwasher has low or no water?
If your Champion Dishwasher has low or no water, the main water supply might be off, the fill hose could be kinked, or the incoming water pressure may be too low. It's also possible that the solenoid valve is defective, the solenoid strainer is clogged, or the circuit board fuse is blown. Try the following: * Open the supply valve. * Straighten the fill hose. * Set the flowing water pressure to 20-22 PSI. * Install a repair kit or replace the valve. * Clean the strainer.
What to do if chemicals won’t feed into my Champion UL130?
If chemicals aren’t feeding into your Champion Dishwasher, it could be due to a low chemical supply, damaged or kinked supply tubing, a clogged pick-up tube, or a blown chemical circuit board fuse. To fix this, refill the chemical container, replace the tubing, straighten the tubing, or clean/replace the tube.
Why does my Champion UL130 Dishwasher have low water pressure from wash spray arms?
Low water pressure from the wash spray arms in your Champion Dishwasher can be caused by a clogged scrap screen, clogged spray arms, or a clogged pump intake screen. Clean the scrap screen and spray arms, and inspect the sump and clean the pump intake screen to resolve this issue.
What to do if water has drained out of the wash tank while the Champion UL130 Dishwasher was idle?
If water has drained out of the wash tank of your Champion Dishwasher while it was idle, it could be because the goose-neck loop in the drain hose has been removed, the drain hose clamp isn't holding the drain hose properly, or the building plumbing doesn't provide the correct air vent to prevent siphoning. Re-route the drain hose (DO NOT STRETCH HOSE) and replace or adjust the hose clamp, ensuring the goose-neck is maintained.
Why are my Champion UL130's wash results poor?
Poor wash results from your Champion Dishwasher may stem from several causes. The water temperature might be too low, or the thermistor could be defective. Issues could also arise from a defective detergent injector, a blown chemical circuit board fuse, or wares incorrectly loaded in the dishrack. Additionally, the booster or wash tank high limit might be tripped. To address this: * Raise the incoming water temperature to 140°F. * Replace the thermistor. * Replace the squeeze tube or injector motor. * Clean the tubing and pick-up. * Reposition wares or reduce the amount of wares in the dish racks. * Reset or replace the high limit.
Why is my Champion Dishwasher staying in the wash cycle?
Your Champion Dishwasher might stay in the wash cycle because the Rinse Sentry extends the wash mode for up to 5 minutes to allow the final rinse water booster temperature to reach 180°F/82°C, or the dishwasher is operating in Extended Wash Mode (UH230B, Only). To resolve this, raise the incoming water temperature, adjust or replace the final rinse booster thermistor, or push the EXT WASH button to exit the Extended Wash mode.
General| Brand | Champion |
|---|---|
| Model | UL130 |
| Category | Dishwasher |
| Language | English |
Guidelines for inspecting, receiving, and positioning the dishwasher.
Procedures for single and three-phase electrical hookups.
Steps to convert booster heater for single to three-phase operation.
Requirements and procedures for connecting the hot water supply.
Guidelines for properly connecting the dishwasher drain hose.
A comprehensive checklist for preparing the dishwasher for first use.
Instructions for filling the booster tank for specific models.
Identifies locations and connections for detergent and rinse-aid pumps.
Procedure to prime the detergent and rinse-aid dispensing pumps.
How to adjust chemical dispensing pump speed and wash tank fill.
Proper methods for loading plates, cups, bowls, and utensils into racks.
Step-by-step guide for running the standard wash cycle.
Procedures for activating and using the extended wash cycle.
How to initiate the drain cycle for the dishwasher.
Procedures for cleaning the interior wash tank and spray arms.
Guide for cleaning rinse arms, specific to certain models.
Steps to remove mineral deposits (scale) from the dishwasher interior.
Routine checks and actions to perform on a daily, weekly, and monthly basis.
Instructions for cleaning the chemical dispenser pick-up tubes.
Common problems, causes, and solutions for dishwasher operation.
Visual diagrams and part numbers for replacement components.
Electrical diagrams for the UL130 low-temperature model.
Electrical diagrams for UH130, UH130B, UH230, UH230B models.
Charts illustrating the sequence and duration of machine operations.
Explanation of the interlock circuit for booster and wash tank heaters.
Information on updates and installation of the digital temperature display board.
Diagram showing the connections for the solid-state timer board.
