To Next PageTo Next PageWhat to do if my Champion Dishwasher won't run?
If your Champion Dishwasher won't run, the door may not be completely closed, the main power could be off, or the dishwasher itself might be turned off. Ensure the door is completely closed, check the breaker on the panel, and turn the dishwasher power switch on.
What to do if my Champion UH130 Dishwasher has low or no water?
If your Champion Dishwasher has low or no water, the main water supply might be off, the fill hose could be kinked, or the incoming water pressure may be too low. It's also possible that the solenoid valve is defective, the solenoid strainer is clogged, or the circuit board fuse is blown. Try the following: * Open the supply valve. * Straighten the fill hose. * Set the flowing water pressure to 20-22 PSI. * Install a repair kit or replace the valve. * Clean the strainer.
What to do if chemicals won’t feed into my Champion UH130?
If chemicals aren’t feeding into your Champion Dishwasher, it could be due to a low chemical supply, damaged or kinked supply tubing, a clogged pick-up tube, or a blown chemical circuit board fuse. To fix this, refill the chemical container, replace the tubing, straighten the tubing, or clean/replace the tube.
Why does my Champion Dishwasher have low water pressure from wash spray arms?
Low water pressure from the wash spray arms in your Champion Dishwasher can be caused by a clogged scrap screen, clogged spray arms, or a clogged pump intake screen. Clean the scrap screen and spray arms, and inspect the sump and clean the pump intake screen to resolve this issue.
What to do if water has drained out of the wash tank while the Champion UH130 Dishwasher was idle?
If water has drained out of the wash tank of your Champion Dishwasher while it was idle, it could be because the goose-neck loop in the drain hose has been removed, the drain hose clamp isn't holding the drain hose properly, or the building plumbing doesn't provide the correct air vent to prevent siphoning. Re-route the drain hose (DO NOT STRETCH HOSE) and replace or adjust the hose clamp, ensuring the goose-neck is maintained.
Why are my Champion Dishwasher's wash results poor?
Poor wash results from your Champion Dishwasher may stem from several causes. The water temperature might be too low, or the thermistor could be defective. Issues could also arise from a defective detergent injector, a blown chemical circuit board fuse, or wares incorrectly loaded in the dishrack. Additionally, the booster or wash tank high limit might be tripped. To address this: * Raise the incoming water temperature to 140°F. * Replace the thermistor. * Replace the squeeze tube or injector motor. * Clean the tubing and pick-up. * Reposition wares or reduce the amount of wares in the dish racks. * Reset or replace the high limit.
Why is my Champion Dishwasher staying in the wash cycle?
Your Champion Dishwasher might stay in the wash cycle because the Rinse Sentry extends the wash mode for up to 5 minutes to allow the final rinse water booster temperature to reach 180°F/82°C, or the dishwasher is operating in Extended Wash Mode (UH230B, Only). To resolve this, raise the incoming water temperature, adjust or replace the final rinse booster thermistor, or push the EXT WASH button to exit the Extended Wash mode.
General| Brand | Champion |
|---|---|
| Model | UH130 |
| Category | Dishwasher |
| Language | English |
Covers defects in material and workmanship for new machines.
How to connect the dishwasher to a single-phase power supply.
How to connect the dishwasher to a three-phase power supply.
Steps to reconfigure the booster heater for three-phase operation.
Requirements for connecting the hot water supply.
Instructions for connecting the drain hose.
A comprehensive checklist before first operation.
Procedure to fill the booster tank for specific models.
Table of common problems, their causes, and recommended solutions.
Steps to diagnose and fix issues when the unit does not start.
Steps to diagnose and fix problems with water intake.
Steps to diagnose and fix chemical dispensing issues.
Steps to diagnose and fix ineffective washing performance.
Illustrated parts breakdown and list for the booster assembly.
Electrical schematics for UL130 and High Temp models.
Wiring diagram for the UL130 low temperature model.
Wiring diagram for UH130, UH130B, UH230, UH230B models.
Interpreting codes displayed for wash temperature conditions.
Interpreting codes displayed for rinse temperature conditions.
Interpreting codes for booster thermistor issues.
Shows how to connect components to the solid state timer board.
Guide to diagnose and resolve problems with the timer board.
Procedures for testing the functionality of timer board components.
