5.Starting of the Engine
5.1 Recoil starting
(1)Open the fuel cock.
(2)Set the speed control lever to “START” position.
(3)Hold the recoil starting handle.
A.Pull out the handle to the position where you feel strong resistance, and then return it to the
initial position.
B.Push down the decompression lever. It will return
automatically when the engine start.
C.Start: Pull on the recoil starting handle use two hand
until you feel resistance, pull the rope hard and fast.
D.In cold weather, when your engine is hard to start,
remove the rubber plug of the cylinder head cover and add
2ml of lube oil before starting.
Note:
It is important to tighten the rubber plug of the cylinder head cover except when adding oil. If
the plug is not in place, rain dirt and dust may enter the engine, and cause accelerated wear of
internal parts, then it can cause serious problems.
