Chaparral 2012 SSi - Page 46

3-11
A
A
B
B
AC
A
ACA C
196 SSI WIDE TECH DECK PLAN
206 SSI WIDE TECH DECK PLAN
TYPICAL 196 SSI, 206 SSI WIDE TECH PROFILE
A - Strong points for anchoring or docking
B - Sling locations
C - Trailering eye
Figure 3.6 206 SSI, 196 SSI
1
2
3
4
5
6
78
9
TYPICAL SSI ENGINE COMPARTMENT LAYOUT
1. Fire Extinguishing System
2. Engine
3. Trim Pump
4. Battery Location - Under Lift Out Cooler Tub
5. CE Manual Bilge Pump (option)
6. Blower
7. Bilge Pump
8. Fuel Tank
9. Steering System
