To ensure the correct rated heat input to the maximum and minimum heat input, it is necessary to
update the speed (rpm) of the fan, it depends on the lenght of the pipes (par. 12), in accordance with
the installation of flue and air pipes as indicated in the tables below. The factory-set value is referred
to the minimum length of flue pipe (0÷4 m for concentric, 0÷20 m for twin). To carry such updating,
changing the speed of the fan (rpm) at the maximum and minimum heat input, refer to par. 15.
COAXIAL PIPE Ø 80/125
(C13-C33-C43)
Pipes length
(m)
0 - 4
5 - 10
Parametres
H536-H613
Max heat output (rpm)
5500
5900
Parametres
H612
Min heat output (rpm)
1900
2100
TWIN-PIPE Ø 80
(C13-C33-C43-C53-C83)
Pipes length
(m)
0 - 20
21 - 40
41 - 60
Parametres
H536-H613
Max heat output (rpm)
5500
5700
5900
Parametres
H612
Min heat output (rpm)
1900
2000
2100
1.45 FF HTE
COAXIAL PIPE Ø 80/125
(C13-C33-C43)
Pipes length
(m)
0 - 4
5 - 10
Parametres
H536-H613
Max heat output (rpm)
5600
6000
Parametres
H612
Min heat output (rpm)
1650
1800
TWIN-PIPE Ø 80
(C13-C33-C43-C53-C83)
Pipes length
(m)
0 - 20
21 - 40
41 - 60
Parametres
H536-H613
Max heat output (rpm)
5600
5800
6000
Parametres
H612
Min heat output (rpm)
1650
1800
1800
1.55 FF HTE
COAXIAL PIPE Ø 80/125
(C13-C33-C43)
Pipes length
(m)
0 - 4
5 - 10
Parametres
H536-H613
Max heat output (rpm)
6000
6500
Parametres
H612
Min heat output (rpm)
1850
2100
TWIN-PIPE Ø 80
(C13-C33-C43-C53-C83)
Pipes length
(m)
0 - 20
21 - 40
41 - 60
Parametres
H536-H613
Max heat output (rpm)
6000
6200
6500
Parametres
H612
Min heat output (rpm)
1850
1900
2100
1.65 FF HTE
12.1 Fan rpm updating
depend of pipes
lenght (e.g. figure 7)
