Chappee 1.65 FF HTE - Page 26

26
Table 2
Table 2.1
Counter clockwise
Model turns of screw
(V)
1.45 FF HTE 3
1.55 FF HTE 3
3
/
4
1.65 FF HTE 4
3
/
4
Table 3
Table 1
Gas consumption at 15 °C
1013 mbar
1.45 FF HTE 1.55 FF HTE 1.65 FF HTE
gas
G20 - 2H - 20 mbar
PCI (
MJ/m
3
)
34.02 34.02
34.02
Consumption at max. heat output (m
3
/h)
4.91 6.00 7.08
Consumption at min. heat output (m
3
/h)
1.58 1.69 2.11
Gas nozzle (mm) 8.5 15 ---
Gas consumption at 15 °C
1013 mbar
1.45 FF HTE 1.55 FF HTE 1.65 FF HTE
gas
G31 - 3P - 37 mbar
PCI (MJ/Kg) 46.34 46.34 46.34
Consumption at max. heat output (Kg/h)
3.60 4.40 5.20
Consumption at min. heat output (Kg/h)
1.16 1.24 1.55
Gas nozzle (mm) 8.5 15 ---
G20 - 2H - 20 mbar G31 - 3P - 37 mbar
CO
2
max. heat output 8.7 % 10 %
CO
2
min. heat output 8.4 % 9.8 %
